旋裝式全流型機油過濾器, LUBE FILTER, SPIN-ON FULL FLOW

P502007

Outer Diameter	81 mm (3.19 inch)
Thread Size	M20 x 1.5
Length	86 mm (3.39 inch)
Gasket OD	64 mm (2.52 inch)
Gasket ID	54 mm (2.13 inch)
Efficiency 99%	39 micron
Efficiency Test Std	ISO 16889
Anti-Drainback Valve	Yes
Bypass Valve	Yes
Bypass Valve Setting LR	0.8 bar (12 psi)
Bypass Valve Setting HR	1 bar (15 psi)
Media Type	Cellulose
Collapse Burst	6.9 bar (100 psi)
Type	Full-Flow
Style	Spin-On
